FDA Aluminum Lightweight Foldable Power Electric Wheelchair
FDA Aluminum Lightweight Foldable Power Electric Wheelchair
| Model | JBH-D09 | Imperial | Metric |
| Specification | Unfolded Dim(LxWxH) | 38.8x23.6x37.4inch | 985×600×950mm |
| Folded Dim(LxWxH) | 23.6x14x31.1inch | 600×355×790mm | |
| Width of Armrests | 19'' | 480mm | |
| Seat Width | 19'' | 480mm | |
| Seat Depth | 16.5' | 420mm | |
| Seat Height | 19.7'' | 500mm | |
Pedal High
From Ground
| 3.2'' | 13.5mm | |
| Packing Carton(LxWxH) | 27.2x16.9x34.6inch | 690x430x880mm | |
| Weight | N.W. (Without Battery) | 51.7lbs | 23.5kg |
| N.W. (With battery) | 58.3lbs | 26.5kg | |
| GW | 32kg | 70.4lbs | |
| Performance | Max Speed | 3.75mph | 6km/hr |
| Loading Capacity | 396lbs | 180kg | |
| Climbing Slope | Max 12° | ||
| Motor | Type | DC Brushless motor | |
| Motor | 250W×2pc (500W) | ||
| Battery | Type | Lithium Battery | |
| Voltage | 24V | ||
| Current | 24V 6AHx2pcs | ||
| Power | 144WH | ||
| Range | 15.5miles | 25KM | |
| Weight | 3.3lbs | 1.5kg/pc | |
| Intput Voltage | 100~240VAC 50/60Hz | ||
| Charger | Output Voltage | 24V | |
| Charging Time | 6~8H | ||
| Tires | Front Tires | 8" PU solid tires | |
| Rear Tires | 12" PU solid tires | ||
| Brake System | Brake | Electromagnetic Brake | |
| Others | Material | Aluminum Alloy | |
| Drive Mode | Rear Drive | ||
| Color | Silver, Black, Blue, Yellow, Red &Pink | ||
| Container | one 20FCL=98pcs, one 40HQ=250pcs | ||
| Warranty |
3 months for cushion and tires
12 months for motor, battery and controller
36 months for frame
| ||
Lightweight
Great Load Capacity
Folding, Lightweight, ElectricFits easily into the trunk of most vehicles.Small and portable for all car, train, and airplane travel.Safely supports up to 396 lbs.Lightweight aluminum- Alloy frame, only 58.5 lbs including battery weight.
Electric Wheelchair D09
Lightweight but Strong
Fits easily into the trunk of most vehicles,folded measurements 77 x 26cm
Small and portable for all car, train, and airplane travel
Safely supports up to 180kg/396lbs
Lightweight aluminum-alloy frame, only 26.5kg/58.5lb including battery weight
Removable, washable seat cushion and back rest (washable up to 95℃)
Solid front and rear tires - no more punctures
Flip-up foot rest
Reliable, easy to use 360° joystick controller
11.5cm/4.5" ground clearance - comparable with the top all-terrain models
Two quiet brushless motors for ultimate power
Intelligent electromagnetic brake (electronic regenerative disc brake) to ensure passenger safety
Reliable and precise battery-life indicator
24V/12AH Lithium battery - chargeable on or off board
Choice of colors,silver, black, red, pink or blue
Small and portable for all car, train, and airplane travel
Safely supports up to 180kg/396lbs
Lightweight aluminum-alloy frame, only 26.5kg/58.5lb including battery weight
Removable, washable seat cushion and back rest (washable up to 95℃)
Solid front and rear tires - no more punctures
Flip-up foot rest
Reliable, easy to use 360° joystick controller
11.5cm/4.5" ground clearance - comparable with the top all-terrain models
Two quiet brushless motors for ultimate power
Intelligent electromagnetic brake (electronic regenerative disc brake) to ensure passenger safety
Reliable and precise battery-life indicator
24V/12AH Lithium battery - chargeable on or off board
Choice of colors,silver, black, red, pink or blue
Colorful, Stylish
High Quality
Both side lithium-ion battery, easy for users installing and charging
Simple touch for folding and unfolding, quick and easy, compact folded size
Alloy frame makes lightweight and easy to carry
Detachable lithium-ion battery for easy to take away, light and safe
Armrest upward movement design for easy to mount on chair
Simple touch for folding and unfolding, quick and easy, compact folded size
Alloy frame makes lightweight and easy to carry
Detachable lithium-ion battery for easy to take away, light and safe
Armrest upward movement design for easy to mount on chair
The FDA Aluminum Lightweight Foldable Power Electric Wheelchair was built with people like you in mind. Something to keep you happy. Every. Single. Day.
