8inch 24V 250W Gear Motor Electric Wheelchair Lithium Battery Tractor DIY Rear Power Assisted Intelligent Conversion Kits Smart

8inch 24V 250W Gear Motor Electric Wheelchair Lithium Battery Tractor DIY Rear Power Assisted Intelligent Conversion Kits Smart

Brand Name: kun ray
Voltage: 24V
Design: Brushless
Wattage: 201 - 300w
Motor Type: Low-speed Brushless Motor
Voltage: 24V
Watt: 250W
Weight After Packing: About 12KG
Motor Operating Current: <3A
Torque: As the picture list
Motor Max Speed: 8km+-1km/h About
Inlcude Battery 24V 8.8Ah: Yes
Size: 8inch
Charger inout voltage: AC 220V
Working Temperature: -20 - + 60
bldc controller proctect vol: 21+-0.5V
Charger Output Current: DC 2+-0.2A
Motor Min Speed: 2.5km+-1km/h About
Batter Type: Lithium Battery
Usage: Electric Wheelchair Rear Power
Waterproffing Grade: IP54

8inch 24V 250W Gear Motor Electric Wheelchair Lithium Battery Tractor DIY Rear Power Assisted Intelligent Conversion Kits Smart

Details：

Motor Type: 8inch Brushless DC Gear Hub Motor

Hub Motor size: 8", 8 inch

Name: Electric Wheelchair  Power Assist

1.Voltage: 24VDC

2.Power: 250W

3.Controller Rated Voltage: 24V

4.Controller Proctect Vol :21V+-0.5V

5.charger inout voltage: AC 220V

6.Charger Output Current:DC 2+-0.2A

7.Motor Operating Current: <3A

8.Motor Speed: min 2.5km+-1km/h About, max 8km+-1km/h About

9.Batter Type: Lithium Battery 24V 8.8Ah

10.Waterproffing Grade: IP54

11.Working Temperature:-20  -  60degree

12.Material: Aluminum

​13.about 18A. can run about 30km total.

Note:

A..When push the wheelchair, the controller will automatically detect

the running state of the wheelchair and start the motor, pushing the

wheelchair forward, to achieve the assistance effect.

B.. When the need for wheelchair automatically forward, only the

continuous application of the wheelchair thrust, wheelchair can be based

on the actual situation before the uniform.

C.. When the wheelchair backward sliding, the controller will

automatically lock the motor, the faster backward sliding speed,

the greater lock force for motor, to prevent the wheelchair backward sliding.

D.. The Motor is Lightweight and Easy to Install. It can be fit

on essentially any make and type of wheelchair, including folding,

tilt-in space, one-arm drive and standing.

E..Belarus,Russian Federation ,Ukraine(Suggest you choose send by -J-NET)
