EU US No tax BBS02B BBS02 48V 500W Bafang mid drive electric motor kit with 48V 13Ah Li-ion down tube ebike battery with charger

EU US No tax BBS02B BBS02 48V 500W Bafang mid drive electric motor kit with 48V 13Ah Li-ion down tube ebike battery with charger

Brand Name: BAFANG
Voltage: 48V
Design: Brushless
Wattage: > 400w
Motor Type: Brushless Gear Hub Motor
Wattage: 500W
Motor positio: Mid crank drive
Controller: Built in the motor
LCD display: C965/Color display
Current Limit: 25A
charger: 54.6V 2A
Waterproof Grade: IP65
Motor Modle: BBS02B
battery: 48v 13ah 14.5ah 16ah
battery cell: 14.5ah 16ah /Samsung/LG

EU US No tax BBS02B BBS02 48V 500W Bafang mid drive electric motor kit with 48V 13Ah Li-ion down tube ebike battery with charger

About taxes:

Austria  Belgium  Bulgaria  Czech Republic  Germany  Denmark  Estonia Spain  Finland

France  United Kingdom  Greece  Hungary  Ireland   Italy   Luxembourg  Netherlands

Latvia   Poland   Romania  Sweden  Slovenia Portugal Slovakia  Lithuania United States

Russian Canada

No taxes, taxes is  paid by us , Free gift Wrench tool

How do I know if the mid drive conversion kits will fit my bike:

This mid drive motor fits for the bike with 68mm or 73mm wide bottom bracket

The inner diamater of the bracket should be not less than 33.5mm

This motor BB Length  68mm Suitable for 68mm or 73mm length Bike Modification



BBS01B  BBS02B: Chain Wheel:

44T 46T 48T 52T (You can note in the order)

Brake Lever change these to Brake Sensor (You can note in the order)





With an integrated speed sensor, this mid-drive motor, which is compatible with standard bikes,

has a rated power of 500W, a reduction ratio of 1: 21.9 and a maximum torque of 100 N.m,

providing ideal power for vehicles. Light but strong and efficient, this motor greatly enhances

riding comfort and is suitable for touring bikes and commuter bikes. This motor is black.

Battery Cello

48V 17.5  14.5  Samsung   48V 16AH LG

Dimension   368*90*110mm

Weight        ≤ 4.5kg

Working temperature

Charge Temperature             0~45°C

Discharge Temperature       -20~65°C

Retention of charge (store in one month)     ≥95%

Rated Voltage                   48V

Rated Capacity C1         ≥ 13AH 14.5AH 16Ah

Battery Resistance        ≤100mΩ

Charge

Way of Charge   CC/CV(Constant Current;Constant Voltage)

Standard Charge Current      2A

Max Charge Current             4A

Max Charge Voltage             54.6V

Cell OverCharge Protection Voltage      4.2V/Cell

Discharge

Max Discharge Current              30A can be customized

Discharge Cut-off Voltage          39V

Cell Overdischarge Protection Voltage     3.0V/cell

Ratio Discharge

1C               >96%C1

2C               >93%C1

3C               >90%C1

Cycle Life    ≥ 800 Cycles

The EU US No tax BBS02B BBS02 48V 500W Bafang mid drive electric motor kit with 48V 13Ah Li-ion down tube ebike battery with charger is evocative, to say the least, but that's why you're drawn to it in the first place.
